    Lincoln Power Wave S350

    Lincoln Power Wave S350

    Product Description

    Features:
    • PowerConnect™ Technology (Patent-Pending) - Automatically adjusts to input power from 200-600V, 50 or 60 Hz, single phase or three phase. Welding output remains constant through the entire input voltage range.
    • Tribrid™ Power Module - Exceptional welding performance with high power factor and efficiency.
    • CheckPoint™ and Production Monitoring™ 2.2 – Use your server or our cloud-based server to view or analyze your welding data on almost any device – desktop, laptop, iPhone® or iPad®, Blackberry® and others. Track equipment usage, store weld data, configure fault limits and more.
    • Optional 115V (10A) AC Duplex Auxiliary Power Receptacle – Features patentpending Surge Blocker™ Technology to ensure simultaneous welding performance is not compromised by high starting current devices such as grinders (typically requiring 60A or more peak surge current).
    • Compact and Durable Case - IP23 rated to withstand harsh environments.
    • Standard Ethernet - Allows for effortless software upgrades through powerwavesoftware.com


    Product Specifications:
    Product Name Power Wave S350 Power Wave S350 Ready-Pak
    Product Number K2823-3 K3005-3
    Input Voltage 208/ 230/ 380 - 415/ 460/ 575/ 1/ 3/ 50/ 60
    Input Current @ Rated Output 3 Ph/ 40% Duty Cycle: 39/ 35/ 19/ 17/ 14
    3 Ph/ 100% Duty Cycle: 31/ 28/ 15/ 14/ 11
    1 Ph/ 40% Duty Cycle: 60/ 67 (1)/ NA/ NA/ NA
    1 Ph/ 100% Duty Cycle: 60/ 53/ NA/ NA/ NA
    Rated Output Current/ Voltage/ Duty Cycle GMAW: 350A/ 31.5V/ 40% (2)
    GMAW: 300A/ 29V/ 100%
    SMAW: 325A/ 33V/ 40% (2)
    SMAW: 250A/ 30V/ 100%
    GTAW-DC: 350A/ 24V/ 40%
    GTAW-DC: 300A/ 22V/ 100%
    Output Range (3) 5 - 350A
    H x W x D Inches (mm) 20.40 x 14 x 24.80 (518 x 356 x 630) 52 x 39 x 26 (1321 x 991 x 660)
    Net Weight/ lbs. (kg) 85 (38.6) 450 (204.1)

    (1) Based on the U.S. National Electrical Code
    (2) On 230 Volt / 1 Phase inputs, the peak rating is at a duty cycle of 30%, except for GTAW processes
    (3) On 208 Volt inputs, the maximum output is limited to 300 amps
