Weldone IA5000

Weldone IA5000

Product Description

Features:
  • Small in size, light weight and easy to carry
  • Good performance with automatic compensatoin for voltage fluctuation
  • Low open energy wastage, energy saving
  • Suitable for welding of stainless steel and mild steel products


Technical Parameter:
Model Weldone IA5000
Input Voltage (V) 3PH 415V 50/ 60Hz
Rated Input Power Capacity (KVA) 21
No-Load Voltage (V) 75
Output Current Range (A) 20 - 500
Rated Output Voltage (V) 32
Duty Cycle (%) 60
Electrode Diameter (mm) 1.6 - 5.0
Efficiency (%) 85
Power Factor (Cos Ø) 0.93
Insulation Class F
Gross Weight (kg) 20
Overall Dimension (mm) 470 x 260 x 465
Protection Class Of Case IP23
